This document tells how to get a Hauppauge WinTV-HVR-950 running on Ubuntu 8.04 Hardy Heron + Mythbuntu. I already have a Hauppauge PVR-350; both devices work together just fine.
There's more Myth info on the MythTV page.
The universal and very power software for watching digital TV and listening to radio channels. Support for various types of sources: - internet TV and Radio. DiSEqC1.2 Support - Tested only with SkyStar1 and SkyStar2 (modified drivers by MiBi) Categories: Main Categories: Capture/Record, DVB (Digital TV, HDTV, Satellite). Dec 05, 2019 DTV-DVB DTV-DVB UDTT 704J – USB 2.0 dual DVB-T Driver driver download and installation. Drivers may also be available for free directly from manufacturers’ websites. All the drives employ a high-speed USB 3. Acer Extensa based on Acer Columbia. DVB Tools, ATSC Tools, ISDB Tools Tools for Analysis and Monitoring of Digital TV and Mobile DTV. TV Viewer, ASN.1 Decoder, HLS Player, TS Player. DTV-DVB Mantis BDA Receiver driver are classified under the monitor and video cards category. The device is manufactured by Samsung. It is compatible with Windows 98, 2000, NT, 2003 and XP platforms. Additional requirements include Windows 98 SE and ME.
Intro
There are a bunch of WinTV-HVR-950s out. As far as I can tell, they all have the same capabilities on Linux: just tune to an ATSC stream and provide it via DVB. The Linux drivers don't support the analog inputs yet.
So, just get the cheapest. Mine is the SL-1139-V2.3-US.
If you get the more expensive device, I think you can just substitute 'em28xx-dvb' below every time you see 'au8522'. Not sure. See [1] for more.
Procedure
We need to use the latest V4L drivers. The ones shipped with Hardy Heron aren't even close to working.
Remove Old Modules
Drivers Dvb-dtv Drivers
Hardy's modules conflict with the newer V4L. Just move them out of the way entirely (this moves them to /root/2.6.24-19-generic-kernel-drivers-media).
This is safer than just deleting them. If V4L screws your machine up somehow, you can just 'sudo rm -rf /lib/modules/`uname -r`/kernel/drivers/media; mv /root/`uname -r`-kernel-drivers-media-backup /lib/modules/`uname -r`/kernel/drivers/media' to restore Hardy to exactly the way you left it.
Install Firmware
Install V4L
Reboot
I know, rebooting sucks. But it's a lot more reliable than crazy stuff like 'make reload'.
Plug in the HVR-950 and reboot. Your HVR-950 should just auto-recognize and the drivers should load fine. Look for something like this in your log messages:
This means it was found.
Ensure it Works
Scan for Channels
I'm using us-ATSC-center-frequencies-8VSB, the table for terrestrial HD broadcast in the US. You'll need to choose whatever is appropriate for your region.
Watch DVB using MPlayer
Change channels with h and k, volume with 9 and 0. Everything should just work.
Only a single program can use the DVB device at once. If you've already set up MythTV, the back-end will be monopolizing it, and you must run 'sudo /etc/init.d/mythtv-backend stop' before running mplayer. When you're done with mplayer, of course, 'sudo /etc/init.d/mythtv-backend start'.
Set up MythTV
This doesn't work yet. I don't know why.
Drivers Dvb-dtv Golf Clubs
Backend
Start the MythTV Backend Setup (System -> Administration).
- Capture Cards -> New capture card
- Card Type: DVB DTV capture card
- The card should now auto-detect and you'll see 'Frontend ID: Auvitek AU8522'
- Finish
- Video Sources
- I don't know if you need to set up a separate video source or not..? I did, just to be safe.
- Input Connections -> DVB:0
- Enter a display name and tell it to use your new video source.
- Scan For Channels.
- I used the '(5-1) Minus' ATSC Channel Separator.
- It will take a long time but it should find a bunch of channels.
- Channel Editor
- You should now see all your new HD channels.
Quit the backend setup. No need to mythfilldatabase.
Front End
Fire up the MythTV front end and watch TV.
Drivers Dvb-dtv Xerox
If you currently have an analog card, you'll need to switch sources. Hit Menu -> Switch Source and select the HD source you set up above.
Drivers Dvb-dtv 64
Everything should just work!
